ASUS RT-N12+ B1 Wireless-N300 3-In-1 Router/AP/Range Extender
- Multiple 3-in-1 Router / Repeater / Access Point wireless modes.
- Two external high-performance antennas for more powerful and wider coverage.
- 300 Mbps high speed.
Consistently Praised for Networking Excellence!
Recommended Excellence Award for Best Router Brand, PC Pro Technology Excellence Awards 2016.
3-in-1 Router Especially Designed for Small Business and Home Network
ASUS RT-N12 B1 is a 300Mbps Wireless N Router with both wired and wireless network connections designed specifically for small business and home office networking use. With 2T2R MIMO Technology and the external high-performance antenna, the RT-N12 B1 creates an extended coverage area with advanced wireless performance, making it ideal for streaming HD video, placing VoIP calls and online gaming. With the ASUS unique Quick Internet Setup and Graphical User Interface, the RT-N12 B1 is easy for anyone to install and manage, even for novices!
Powerful wide-range coverage
Enhanced signal strength and wider coverage for larger homes and offices are driven two external high-performance antennas. The design is also ideal for multi-floor locations with devices located on different levels.
Dedicated Wi-Fi for your visitors
Share your internet connection with your guests with no need to share your personal password or network resources. ASUS Guest Network supports up to three separate guest networks, each with its own usage limits and password. Guests cannot access your primary network or any other connected devices.
Robust control and optimization with ASUSWRT
With the ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. The whole-new dashboard interface lets you manage all clients and settings via a single graphical interface, and provides 1-click updates. Try our ASUSWRT.
Easy 3-step setup
Use your smartphone, tablet, or PC to effortlessly set up your ASUS router in less than 30 seconds¹ and in only 3 easy steps. Simply connect the cables to the router, open a Web browser, and follow the setup wizard to get you to the internet in no time.
Step1: Open web browser.
Step2: Enter ID/Password.
¹ASUS-tested and verified setup time. Actual duration may vary by ISP, specific connection type, location, and other factors.
Extend Wi-Fi coverage quickly and simply
Universal repeater mode instantly extends the Wi-Fi range of any standard wireless router, sustaining smooth and fast connections in larger and even multi-floor locations.
Keep Up to Date!
Remember to always keep your device’s firmware up to date so you can benefit from the very latest service and security enhancements — and get exciting new features! Learn more about updating new firmware.
* ASUS received the highest numerical score among wireless routers in the J.D. Power 2015 Wireless Router Satisfaction Report, based on 2,716 responses from 8 companies measuring satisfaction with wireless routers surveyed November-December 2015. Your experiences may vary. Visit jdpower.com
|Network Standard||IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IPv4, IPv6|
|Product Segment||N300 complete networking : 300 Mbps|
|Data Rate||802.11n : up to 300 Mbps|
|Antenna||Fixed antenna x 2|
|Transmit/Receive||MIMO technology 2.4 GHz 2 x 2|
|Operating Frequency||2.4 GHz|
|Encryption||64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support|
|Management||UPnP, IGMP v1/v2/v3, DNS Proxy, NTP Client, DDNS, Port Trigger, Virtual Server, DMZ|
|WAN Connection Type||Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP|
|Utilities||Device discovery, Firmware restoration|
|Ports||RJ45 for 10/100 BaseT for WAN x 1, RJ45 for 10/100 BaseT for LAN x 4|
|– User definable rules for IP/MAC/Port|
|– Upload and download bandwidth management|
|– ACK/SYN/FIN/RST/ICMP with highest priority|
|Guest Network : 2.4 GHz x 3|
|VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server|
|Button||WPS Button, Power Button|
|LED Indicator||Power x 1|
|Wi-Fi x 1|
|WAN x 1|
|LAN x 1|
|Power Supply||AC Input : 110V~240V(50~60Hz)|
|DC Output : 12 V with max. 0.5 A current|
|OS Support||Windows® 10|
|Mac OS X|
|Dimensions||146 x 111 x 24 ~ mm (WxDxH)|
|Operation mode||Wireless router mode|
|Range extender mode|
|Access point mode|
