Specifications

• CPU
  AMD AM4 Socket for 3rd Gen AMD Ryzen™ and 3rd Gen AMD Ryzen™ with Radeon™ Graphics Processors Processors *
  * Refer to www.asus.com for CPU support list
• Chipset
  AMD A520
• Memory
  4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory *
  Dual Channel Memory Architecture
  ECC Memory (ECC mode) support varies by CPU.
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  * The maximum memory frequency supported varies by processor
• Graphic
  Integrated Graphics in the 3rd Gen AMD Ryzen™ with Radeon™ Graphics Processors
  1 x D-Sub
  1 x DVI-D
  1 x HDMI 2.1(4K@60HZ)
• Expansion Slots
  3rd Gen AMD Ryzen™ and 3rd Gen AMD Ryzen™ with Radeon™ Graphics Processors
  1 x PCIe 3.0 x16 (x16 mode)
  AMD A520 Chipset
  2 x PCIe 3.0 x1
• Storage
  Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports
  3rd Gen AMD Ryzen™ and 3rd Gen AMD Ryzen™ with Radeon™ Graphics Processors :
  1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
  AMD A520 Chipset :
  4 x SATA 6Gb/s port(s),
  Support Raid 0, 1, 10
• LAN
  Realtek L8200A 1Gb Ethernet
  TUF LANGuard
• Wireless Data Network
  M.2 slot only (Key E) (Support PCIe interface)*
  *Wi-Fi module is sold separately.
• Audio
  Realtek ALC887 7.1 Surround Sound High Definition Audio CODEC *
  – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
  Audio Feature :
  – Audio Shielding
  – Dedicated audio PCB layers
  – Premium Japanese audio capacitors
  * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
• USB Ports
  Rear USB Port ( Total 7 )
  1 x USB 3.2 Gen 2 port(s)(1 x Type-A)
  4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
  2 x USB 2.0 port(s)(2 x Type-A)
  Front USB Port ( Total 5 )
  2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
  3 x USB 2.0 port(s)(3 x Type-A)
• Software Features
  ASUS Exclusive Software
  Armoury Crate
  – Aura Creator
  – Aura Sync
  AI Suite 3
  – Performance And Power Saving Utility
  TurboV EVO
  EPU
  Digi+ VRM
  Fan Xpert 2+
  – EZ update
  – PC Cleaner
  – System Information
  TUF GAMING CPU-Z
  AI Charger
  ASUS Turbo LAN
  Norton Anti-virus software (Free Trial for 60 days)
  WinRAR
  UEFI BIOS
  ASUS EZ DIY
  – ASUS CrashFree BIOS 3
  – ASUS EZ Flash 3
  – ASUS UEFI BIOS EZ Mode
• ASUS Special Features
  ASUS TUF PROTECTION
  – ASUS DIGI+ VRM
  – ASUS ESD Guards
  – TUF LANGuard
  – ASUS Overvoltage Protection
  – ASUS SafeSlot Core+
  – ASUS Stainless-Steel Back I/O
  ASUS Q-Design
  – ASUS Q-DIMM
  – ASUS Q-Slot
  ASUS Thermal Solution
  – Aluminum heatsink design
• Back I/O Ports
  1 x PS/2 keyboard/mouse combo port(s)
  1 x DVI-D
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  1 x USB 3.2 Gen 2 (teal blue)Type-A,
  4 x USB 3.2 Gen 1 (blue) Type-A
  2 x USB 2.0
  3 x Audio jack(s)
• Internal I/O Ports
  1 x CPU Fan connector(s)
  2 x Chassis Fan connector(s)
  1 x Aura RGB Strip Header
  1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
  2 x USB 2.0 connector(s) support(s) additional 3 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
  1 x M.2 with E key for Wi-Fi module
  1 x SPI TPM header
  4 x SATA 6Gb/s connector(s)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin EATX 12V Power connectors
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x COM port header
• Accessories
  User’s manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x Supporting DVD
  1 x TUF Gaming Sticker
  1 x TUF Certification card(s)
  1 x M.2 SSD screw package(s)
  1 x M.2 Key E screw package(s)
• BIOS
  256 Mb Flash ROM, UEFI AMI BIOS
• Manageability
  WOL by PXE
• Operating System
  Windows® 10 64-bit
• Form Factor
  mATX Form Factor
  9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
