ASUS XONAR AE 7.1 PCIe Gaming Sound Card

ASUS

  • 192kHz/24-bit Hi-Res audio and 7.1-channel, 150ohm headphone amp
  • High-quality ESS DAC with 110dB signal-to-noise ratio (SNR)
  • Exclusive EMI back plate provides noise shielding for exceptionally clear audio
  • Sonic Studio enables full audio control via an intuitive, one-page interface
  • Perfect Voice technology eliminates background noise for clear in-game communication

 19,980

Compare

ASUS Xonar AE

The Xonar AE 7.1-Channel PCIe Gaming Audio Card from ASUS is a compact 7.1-channel sound card designed to provide Windows 10, 8.1, and 7 users with high-quality audio for games, music, and movies. The Xonar AE has no standalone power supply and connects to your computer via PCIe. It features 192 kHz/24-bit sound, a 150-ohm headphone amp, an ESS DAC with a 110 dB signal-to-noise ratio (SNR), an EMI backplate with ASUS Hyper Grounding technology to help ensure minimal sound distortion and interference, Sonic Studio software to enable full control over your audio, and Perfect Voice technology to help eliminate background noise for clearer in-game communication. Included is an S/PDIF optical adapter and protection is provided by a limited 3-year warranty.

SKU: 4712900633603 Category:
Audio Performance PCI Express
Audio Performance Output Signal-to-Noise Ratio (A-Weighted)
110 dB
Output Signal-to-Noise Ratio (A-Weighted, Headphone-out)
108 dB
Input Signal-to-Noise Ratio (A-Weighted)
103 dB
Output THD+N at 1 kHz (Front-out)<0.00158% (-96 dB)
Input THD+N at 1 kHz
<0.0022% (-93 dB)
Frequency Response (-3 dB, 24-bit/192 kHz input)
10 Hz to 65 kHz
Chipset Audio Processor
C-Media USB2.0 6632AE High-Definition Sound Processor (max. 192 kHz/24-bit)
Digital-to-Analog Converter (DAC) ESS ES9023P (112 dB DNR, max. 192 kHz/24-bit)
Cirrus Logic CS4245 (104 dB DNR, max. 192 kHz/24-bit)
Cirrus Logic CS4361 (103 dB DNR, max. 192 kHz/24-bit)
Sample Rate and Resolution Analog Playback Sample Rate and Resolution
44.1/48/88.2/96/176.4/192 kHz @ 16-/24-bit
Analog Recording Sample Rate and Resolution
44.1/48/88.2/96 kHz @ 16-/24-bit
S/PDIF Digital Output
44.1/48/88.2/96/176.4/192 kHz @ 16-/24bit
ASIO 2.2 Driver Support
44.1/48/96/192 kHz @ 24-/32-bit
Connectivity Analog Output
5 x 3.5 mm jack (1/8″ headphone-out, front-out, side-out, center/subwoofer-out, rear-out
Analog Input
1 x 3.5 mm jack (1/8″) (line-in/mic-in combo)
Digital
1 x S/PDIF out (1 x Optical (Toslink)
Operating System Windows 10, 8.1, and 7 (32-/64-bit)
Please update your BIOS and drivers to the latest version to support Windows 7
Dimensions Not specified by manufacturer
Weight Not specified by manufacturer
