Ease EC124B Tempered Glass Case
Panoramic View
- Fans 4 * 12CM ARGB Fans
Support Water Cooling
- Upper Plate Supports Water Cooling Fan
- Lower Plate Support Water Cooling Fan
- Motherboard Supports Water cooling
Hardware Installations
- VGA Card Length – 410mm
- Micro ATX / ATX
- CPU Height Max : 160mm
Front Ports
- LED Port
- USB 3.0 / Type C
- USB 2.0 * 2
- Audio Ports * 2
- HDD LED / Power LED
- Light Touch Reset Switch
- Light Touch Power Switch
HDD Installations
- Super Compatible With HDD Installations
- 2 HDD s Slots
- 3 SSD s Slots
- Bottom SSD Slot Available
Panoramic View
- Room Without Pillars
- Full View Case
- Super Compatible
- Multi-Channel Cooling
- Transparent and Cool
- Light Illusion
Support 10 Cooling Fans
- Maximum Support 360 MM Liquid Cooler
- Compatible with 280/240/12 MM Liquid Cooler
- Top Position – 3 Coolers
- Bottom Position – 3 Coolers
- Cover Body Case Position – 3 Cooler
- Rear Position – 1 Cooler
High Efficiency Heat Dissiapation Channel
- Vertical Cooling Design
- Enhance Cooling Speed
Support Back-Plug M/G
- Many large wiring holes are reserved on the main board of chassis.
- Perfectly supports back-plug m/b without affecting the installation of traditional m/b.
HDD Installations
- Super Compatible With HDD Installations
- 2 HDD s Slots
- 2 SSD s Slots
- Hardware Capability: 2 HDD + 2 SSD or 1 HDD + 3 SSD
Product Catalogue
| Brand |
|---|
| Model | EC124B | ||
| M/B Form Factor: | ATX/Micro ATX/ITX | ||
| I/O Ports | USB 2.0*2 + USB 3.0*1 | ||
| Material of Chassis | SPCC | ||
| Side panel | SPCC 0.6mm Black case,Black cable with magnetic Amplifier | ||
| Material of front panel | Tempered Glass | ||
| Drive bays | 3.5’’ HDD2, 2.5’’ SSD3 | ||
| GPU clearance | 410mm | ||
| PCI Slots | 7 | ||
| Fan positions | 312 cm fans on bottom panel, 214 cm fans on top panel, 112 cm on back panel, 214cm fans on motherboard panel | ||
| Water coolers compatitble | 360/280/240/120mm on top panel, 360/240/120mm on bottom panel, 280/240/120mm on motherboard panel | ||
| Dimension of Chassis | 420mm×285mm×380mm (L×W×H) | ||
| Case size: | 420mm (Length) × 285mm (Width) × 380mm (Height) | ||
| Packing size | 470x375x526mm | ||
| G.W / N.W | 7.8 kg / 6.8 kg | ||
