EPC i3-7167u Mini PC

 55,500

Product Specification

Basic Information:
CPU Intel Core i3-7167u
TDP 15W
Motherboard 120 x 120mm customized board
BiOS AMI BiOS, ACPI Supported
Chipset Intel KABYLAKE
Memory 1 * SO-DIMM DDR4 Slot, Support 4/8/16/32GB DDR4- 2123, LPDDR3-1866, DDR3L-1600
OS Windows 7/Windows 8/Windows10/Linux
PXE YES
Audio ALC662 sound chip, 6 channel, Intel Panther Point HDA
Network Onboard Realtek RTLR168/r1111/r112 PO-E Gigabit Ethernet NoC
Video Intel Iris Plus Graphics 650
Wi-Fi:
Module 1 x mini PCIE-half port for Wi-Fi module
Antenna 2 x inner RF cables and 2 x external antennas
Power and Working Environment:
Input DC100-240V AC/50-60Hz
Output DC +12v”’19V, recommend 12V/5A
Operating Temperature 0/+70 centigrade
Storage Temperature -20/+85 Centigrade
Relative Humidity 0%-90% (non-cooling)
Input/output port:
Switch 1 x Power On/Off Switch
Power 1 x 12V DC in
LED 2 x LED
USB 2 x USB2.0, 4 x USB3.0
Display 1 x VGA, 1 x HDMI 1.4
LAN 1 x RJ45 Giga LAN
Audio 1 x Mic, 1 x SPK
Others 2 x kennsington lock holes
Storage:
MtSATA 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s
SATA 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s
Product Dimension & Details:
Size 173*127*39mm
Weight Net 0.8kg, Gross 1.2kg
Shell Silver/blue/black Color alluminium alloy(any customized color for bulk order)
Cooling Mode Fanless
Functions Calls on function automatically, Wake-on LAN, Kensington Lock
Package Content:
Standard 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag, 1x Bracket
Optional Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xVESA mount
