EASE PTZ20X 1080P Video Conferencing Camera

EASE
Add to Wishlist
Compare
  • 1080P Full HD video resolution
  • New Generation ISP Image Processing Algorithm for improved image quality
  • Upgraded AI technology for advanced features
  • Leading Auto Focus Technology for clear and sharp images
  • 60° Wide-angle Lens + 20x Optical Zoom for versatile viewing
  • Low illumination for clear image capture in low light conditions
  • AAC Audio Encoding for high quality audio
  • Exclusive Audio Processing Algorithm for improved sound quality
  • Multiple interfaces for ease of use and integration
  • Remote Control for convenient operation.

₨ 194,400

Ad
Compare
EASE PTZ20X 1080P Video Conferencing Camera
20x Optical Zoom + 60.7° Wide-Angle Lens
  • Adopts a high-quality ultra-high-resolution full HD  telephoto lens, supports a maximum of 20x optical zoom, a  35mm equivalent focal length of up to about 670mm, and a  horizontal field of view of 60.7° .
20x Optical Zoom + 60.7° Wide-Angle Lens
  • Adopts a high-quality ultra-high-resolution full HD  telephoto lens, supports a maximum of 20x optical zoom, a  35mm equivalent focal length of up to about 670mm, and a  horizontal field of view of 60.7° .
Upgraded AI Technology
Using upgraded AI technology and pedestrian re-recognition technology, it can accurately determine  the location of each person based on information such  as pedestrian clothing, body shape, hairstyle, and face  recognition, and realize automatic identification and  tracking of target human figures, automatic frame selection,  and intelligent privacy for meetings. Blur function.
Upgraded AI Technology
Using upgraded AI technology and pedestrian re-recognition technology, it can accurately determine  the location of each person based on information such  as pedestrian clothing, body shape, hairstyle, and face  recognition, and realize automatic identification and  tracking of target human figures, automatic frame selection,  and intelligent privacy for meetings. Blur function.
Remote Control
Through the RS232 and RS485 serial ports and USB, the  camera can be controlled remotely.
Remote Control
Through the RS232 and RS485 serial ports and USB, the  camera can be controlled remotely.
EASE PTZ20X 1080P Desc Img 1
SKU: PTZ20X Categories: , , ,
Brand

Model PTZ20X
Name 1080P Professional PTZ Camera With AI Technology
Main Features

Uncompressed Professionally video output

 HDMI、3G-SDI: 1080P60，1080P59.94，1080P50， 1080I60，1080I59.94，1080I50，1080P30，1080P29.97，1080P25， 720P60，720P59.94，720P50
Sensor 1/2.8 inches, CMOS, Effective Pixel: 2.07 Megapixels
Scanning Mode Progressive
Focal length 20x, f4.42mm ~ 88.5mm, F1.8 ~ F2.8
Shutter 1/30s ~ 1/10000s
Minimum Illumination 0.5 Lux @ (F1.8, AGC ON)
White Balance Auto, Indoor, Outdoor, One Push,  Manual
Backlight Compensation Support
Digital Noise Reduction 2D&3D Digital Noise Reduction
SNR ≥ 55dB
Horizontal FOV 60.7° ~ 3.36°
Vertical FOV 34.1° ~ 1.89°
Pan Angle ±170°
Tilt Angle -30° ~ +90°
Pan Speed 1.7° ~ 100° /s
Tilt Speed 1.7° ~ 69.9° /s
Image Flip Support
Image Freeze Support
Preset Position 255
Preset Accuracy 0.1°
Interfaces
USB Interfaces 1 x USB3.0,Type-A
HD Output 1 x HDMI: Version 1.3 ; x3G-SDI: BNC, 800mVp-p, 75Ω, as SMPTE 424M standard
Network Interface 1x RJ45: 10M/100M/1000M adaptive  Ethernet, Support PoE
Audio Interface Built-in dual microphones ,1 x Line In, 3.5mm Jack, 1 x Line Out, 3.5mm Jack
  Control Interface 1 x RS485: 2pin phoenix port, Max  Distance: 1200m, Protocol: VISCA /  Pelco-D / Pelco-P; 1 x RS232 IN: 8pin Mini DIN, Max  Distance: 30m, Protocol: VISCA /  Pelco-D / Pelco-P; 1 x RS232 OUT: 8pin Mini DIN, Max  Distance: 30m, Protocol: VISCA only
Power Interface JEITA type (DC IN 12V)
Audio
Microphone Array Built-in dual microphones, 100Hz to 16KHz frequency response.
Analog Audio Input/Output Support 3.5mm Line-In; Support 3.5mm Line-Out
Digital Audio Output Support HDMI, USB, LAN, 3G-SDI etc.
Network Features
Video Compression H.265 / H.264
Video Stream First Stream, Second Stream
First Stream Resolution 1920x1080, 1280x720, 1024x576 etc.
Second Stream Resolution 1280x720,1024x576,720x576 etc
Video Bit Rate 32Kbps ~ 102400Kbps
Bit Rate Control Variable Bit Rate, Constant Bit Rate
Frame Rate 1fps ~ 60fps
Audio Compression AAC
Audio Bit Rate 96Kbps, 128Kbps, 256Kbps
Protocol NDI®|HB, NDI®|HX, NDI®|HX2, TCP/ IP, HTTP, RTSP, RTMP, Onvif, DHCP,  Multicast,SRT, GB/T 28181etc.
USB Features
  Operating System  Supported Windows® 7 (only 1080P and below  supported), Windows 8.1, Windows 10 or higher macOS ™ 10.10 or higher Google ™ Chromebook ™ Version 29.0.1547.70 or higher Linux (support UVC)
Hardware  Requirements 2.4 GHz Intel® Core 2 Duo CPU or  higher 2 GB RAM or more USB 2.0  interface
Color System /  Compression YUY2 H.264 / MJPEG
Signal System Support variety of video formats  with different frame rates and  resolutions, up to 1080p/60 YUY2  output.
USB Video  Communication Protocol UVC1.1 and UVC1.5
USB Audio 32K Sampling Rate, Support UAC2.0
UVC PTZ Control Support
General Specifications
Input Voltage DC 12V / PoE (802.3af)
Input Current 1.0A (Max.)
Operating Temperature -10° C ~ 40° C
Storage Temperature -40° C ~ 60℃
Power Consumption 12W (Max.)
Dimensions 169mm x 142mm x 164mm
Net Weight 1.35Kg
